CCTV POWER SUPPLY (Metal)
Model Number : 12V10A9CH
Description :
- DC VOLTAGE: 12V
- OUTPUT POWER: 1-360W
- CURRENT RANGE: 0-1.5 Amp (Each channel), Total 0-30 Amp for 18 channels
- RIPPLE & NOISE (Max): 120mVp-p
- VOLTAGE ADJ. RANGE: ±10%
- LINE REGULATION: ±1.0%
- LOAD REGULATION: ±2.0%
- VOLTAGE TOLERANCE: ±2.0%
- VOLTAGE RANGE: 110VAC OR 220VAC Selected
- AC CURRENT (Typ.): 4.5A/110VAC 2.5A/240VAC
- FREQUENCY RANGE: 47-63Hz
- INRUSH CURRENT (Typ.): COLD START 15A/115VAC 30A/260VAC
Place of Origin : China
